Model no.: LWAA Series AC Axial Flowl fan
Impeller Size: 200mm - 800mm (diameter )
Operating Temperature Ranges: -25℃- +60 ℃
Material: Cold Rolled Steel
Diameter: 200mm-800mm
Voltage Ranges: 115V/220V/380V-50/60Hz
Certiticating: CCC, CE
Insulation Class: F
Protection Class: P44
#1. Features:
1. The Fan Blade is designed with advance aerodynamics, which makes the fan artistic and efficient; the Fan rotor adopts double-sided dynamic balance. The dynamic balance achieves G6.3.
The fan blade, rotor and grid is all powder sprayed, the surface is bright appearance, has good corrosion-resistant effect. Motor Cover also by the special treatment.Bright beautiful appearance is no teasy oxidation discolor ration.
2. Fan normal ambient temperature:-25 C～+60 C, if the temperature range in excess soft the above, our factory can be customized according to customer requirements..
3. The insulation grade of currently supplied fan is B-cass and F-class, the protection class is IP54.At present, we can also supply the fan which working environment temperature:-40 C～+60 C and-25 C～+80 C.Can with thermal protection. Our factory new put out the IP56 axial fan motor with new structure soon, and this structure has get national patent, It can apply to the humidity and bad environment.
4. Fan shaves single-phase capacitor running and three-phase asynchronous running. Single-phase motor has 220V/50Hzand 220V/60Hz. Three-phase motor has 380V/50Hz and 380V/60Hz.At the same time can provide customers with the special requirements of the motor, a special voltage, dual voltage and soon.
5. Fan motor can be directly elected, and can provide various form water-proof junction box for the user's selection.
#2 Advantages of our AC axial flow fans
-Long life span ;
-OEM & ODM available ;
-Cold Rolled Steel Materials.
|
Range of diameters |
No of blades |
Voltage Range |
Power |
Air Flow |
RPM |
|
(mm) |
(pcs) |
(V) |
(W) |
(m³/h) |
(RPM) |
|
200 |
5 |
220V-50/60Hz |
25-80 |
425-980 |
1400-2600 |
|
250 |
5,7 |
220V-50/60Hz |
50-170 |
860-2250 |
1400-2900 |
|
300 |
5 |
220V-50/60Hz |
80-155 |
1650-2050 |
1350-2650 |
|
350 |
5 |
220V-50/60Hz |
70-190 |
1560-3000 |
920-1550 |
|
400 |
5 |
220V-50/60Hz |
110-260 |
2600-3900 |
950-1620 |
|
450 |
5 |
220V-50/60Hz |
135-280 |
2900-4800 |
910-1600 |
|
500 |
5 |
220V-50/60Hz |
220-500 |
4320-6800 |
900-1500 |
|
550 |
5 |
220V-50/60Hz |
280-725 |
6500-8500 |
910-1540 |
|
600 |
5 |
220V-50/60Hz |
500-1000 |
8500-11000 |
910-1640 |
|
630 |
5 |
220V-50/60Hz |
520-1150 |
9300-11000 |
900-1540 |
|
710 |
7 |
380/400v-50Hz |
450-1100 |
10000-17000 |
600-900 |
|
800 |
7 |
380/400v-50Hz |
1250-1850 |
19000-25000 |
700-900 |
FAQ:
1, Are the manufacturer ?
Yes, LONGWELL is a professional manufacturer which is the specialist in HVACR fans, motor and components for the applications of air conditioner, air ex-changer, coolers, heaters, floor convectors, sterilization purifier, air purifiers, medical purifiers, and ventilation, energy industry, 5G cabinet ...
2. What's your advantages of technologies in fans and motors ?
We makes very quiet noise and good air performances of fans,
We are capable to do fans and motos matching and make them optimized to achieve best air performances and lowest noise with CFD simulation.
