Model Dimesions: 220mm EC Electric plenum centrifugal fan
EC external rotor motor: 230V/115V 50/60Hz
Power Input Range: 85W~180W
Max Air Flow Ranges: 910~1350 m³/h
Max Air Pressure: 430~1100 Pa
IP Level: IP 55, IP 54
Speed Control: Control Input 0-10VDC / PWM
Life expectance: 50,000Hours(L10),At 40℃ room, humidity 15%~65%RH.
Electronic Protection: Locked-rotor Protection; Locked-Rotor Protection; Over- Current Protection; Over- Voltage Protection; Soft Start; Reverse Polarity Protection
Ambient Temp Ranges: -25 ℃ - +60 ℃ Transformer air cooling




Applications

Special Features:
Support structure / cube design
Easy to install in VACT
Complete system, fast and simple installation
Equipped with wall panels, the fan can be easily installed on the outer wall of the unit
Horizontal and vertical motor shaft installation
Compact design and high structural freedom
Perfect example of aerodynamics
The optimized wind ring has been positioned at the factory
Effectively reduce vibration
