Type: LONGWELL AC DC EC electric centrifugal reversible axial ventilation inline duct fan
Model no: 4 INCH 5inch 6 inch 8 inch 10inch 12inch
Material: Plastic
Voltage: 115v, 230V
Motor Type: AC external rotor motor
Housing Material: Plastic +GF
Impeller Material: Plastic / Galvanized Steel
Insulation Class: F
Certification: CE/CCC
Operation Temperature: - 20 ℃ ~ +60 ℃
Payment: T/T, L/C, West Union, etc
● Designed to quietly ventilate grow tents, exhaust odors, transfer heating/cooling to rooms, and cool AV closets.
● Features the same build quality and innovations as the CLOUDLINE Series delivered in a value package.
● Mixed flow design combined with an EC-powered motor for a truly quiet and energy efficient performance.
Model | Voltage | Frequency | Gear | Power | Current | Speed | Air Flow | Pressure | Noise |
(v) | (Hz) | （W） | （A） | (RPM) | （m³/h） | （Pa） | （dBA） | ||
LWDAPS-100 | 220-240 | 50 | H | 36 | 0.16 | 2360 | 325 | 163 | 30 |
L | 25 | 0.11 | 1900 | 205 | 135 | 24 | |||
110-120 | 60 | H | 34 | 0.29 | 2360 | 325 | 163 | 30 | |
L | 34 | 0.23 | 1900 | 205 | 135 | 24 | |||
LWDAPS-125 | 220-241 | 50 | H | 39 | 0.18 | 2360 | 330 | 168 | 31 |
L | 28 | 0.14 | 1950 | 293 | 137 | 30 | |||
110-121 | 60 | H | 37 | 0.31 | 2360 | 330 | 168 | 31 | |
L | 29 | 0.24 | 1950 | 293 | 137 | 30 | |||
LWDAPS-150 | 220-242 | 50 | H | 59 | 0.22 | 2400 | 660 | 168 | 32 |
L | 41 | 0.19 | 2050 | 530 | 137 | 30 | |||
110-122 | 60 | H | 59 | 0.49 | 2480 | 674 | 355 | 32 | |
L | 44 | 0.36 | 2050 | 535 | 302 | 30 | |||
LWDAPS-200 | 220-243 | 50 | H | 130 | 0.6 | 2300 | 910 | 384 | 40 |
L | 113 | 0.55 | 1650 | 735 | 303 | 38 | |||
110-123 | 60 | H | 182 | 1.59 | 2480 | 1250 | 435 | 41 | |
L | 128 | 1.06 | 1950 | 750 | 303 | 38 |
Quiet And Energy Efficient Design
The inline fan features a mixed flow design using a stator blade and dual hydrodynamic wind circles. This gives it a high static pressure rating, enabling it to deliver airflow even in applications where air movement is being restricted. The motor houses dual ball bearings rated at 67, 000 hours which allows the duct fan unit to be mounted in any direction. In addition, the inline fan is crafted with a plastic mounting base to diminish noise as a result of fan vibration. The unit is IP44 rated to be highly resistant to dust and liquids and performs well even in harsh environments.
This quiet inline fan system is most found in hydroponic grow tents and rooms to provide cooling and ventilation for plants. Its low noise and advanced control features make it fit for bathroom and attic settings, as well as cooling AV equipment rooms, closets, racks, and cabinets.
LONGWELL is a professional manufacturer of fans, blowers, motors and components for heating, venlation air conditioner and refrigeration applications, specialist in centrifugal fans, axial fans, ac /BLDC cross flow fans, single/double forward curved fans, AC/BLDC/ECM motors as well as industrial fan blowers, established in 1990, equipped with high advanced testing labs and production facilities including B&K noise lab, CFD simulation lab, air dynamics test chamber, automatic welding machines, CNC machining centers, auto robot injection machines which makes over millions fans capacity annually. With over than 28 years manufacturing experiences, LONGWELL is very skilled in designing, developing and manufacturing of fans and motors, and exporting to over 30 countries including many Fortune Global 500 customers in HVACR application. And products complied with certificates of CCC，CE, ETL and UL.
