Model no.: CJX2 AC Contactor
CJX2 AC Contactor
● 1.Remote make & break of circuits.
● 2.Frequent start and stop of motor.
Motor P(KW) 380V | Rated current (A) | Auxiliary contact | Refernece | |
5.5 | 9 | 1 | 0 | CJX2910 |
7.5 | 12 | 1 | 0 | CJX21210 |
0 | 1 | CJX21201 | ||
10 | 18 | 1 | 0 | CJX21810 |
0 | 1 | CJX21801 | ||
15 | 25 | 1 | 0 | CJX22510 |
0 | 1 | CJX22501 | ||
18.5 | 32 | 1 | 0 | CJX23210 |
0 | 1 | CJX23201 | ||
30 | 49 | 1 | 1 | CJX24011 |
33 | 50 | 1 | 1 | CJX25011 |
37 | 65 | 1 | 1 | CJX26511 |
45 | 80 | 1 | 1 | CJX28011 |
55 | 95 | 1 | 1 | CJX29511 |
■ Technical Data
Model | CJX2-09 | CJX2-12 | CJX2-18 | CJX2-25 | CJX2-32 | CJX2-40 | CJX2-50 | CJX2-65 | CJX2-80 | CJX2-95 |
Rated operational voltage | 400,690 | |||||||||
Rated insulational voltage | 690 | |||||||||
Conventional thermal current | 25 | 25 | 32 | 40 | 50 | 60 | 80 | 80 | 125 | 125 |
● Rated operational Current
Model | CJX2-09 | CJX2-12 | CJX2-18 | CJX2-25 | CJX2-32 | CJX2-40 | CJX2-50 | CJX2-65 | CJX2-80 | CJX2-95 |
400V AC-3 (A) | 9 | 12 | 18 | 25 | 32 | 40 | 50 | 65 | 80 | 95 |
400V AC-4 (A) | 3.5 | 5 | 7.7 | 18 | 21 | 34 | 39 | 42 | 49 | 55 |
690V AC-3 (A) | 6.6 | 8.9 | 12 | 8.5 | 12 | 18.5 | 24 | 28 | 37 | 44 |
690V | 1.5 | 2 | 3.8 | 4.4 | 7.5 | 9 | 12 | 14 | 17.3 | 21.3 |
● Power of controlled 3-phase cage motor
Model | CJX2-09 | CJX2-12 | CJX2-18 | CJX2-25 | CJX2-32 | CJX2-40 | CJX2-50 | CJX2-65 | CJX2-80 | CJX2-95 |
400V AC-3 (KW) | 4 | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 |
690V AC-3 (KW) | 5.5 | 7.5 | 10 | 15 | 18.5 | 30 | 33 | 37 | 45 | 55 |
400V AC-4 (KW) | 2.2 | 3 | 4 | 5.5 | 7.5 | 7.5 | 11 | 15 | 18.5 | 22 |
● Electric durabilities
Model | CJX2-09 | CJX2-12 | CJX2-18 | CJX2-25 | CJX2-32 | CJX2-40 | CJX2-50 | CJX2-65 | CJX2-80 | CJX2-95 |
AC-3 x104 operations | 100 | 80 | 80 | 60 | ||||||
AC-4 x104 operations | 20 | 20 | 15 | 10 | ||||||
■ Working conditions
● Ambient temperature: -5℃ ~+40℃，the daily average temperature ≤35℃
● Altitude: ≤ 2000m
● Humidity: Maximum temperature is +40℃, air relative humidity of not more than 50%, at a lower temperature allows a higher relative humidity. For example, 20 ℃ when up to 90%, and occasionally due to temperature changes resulting from Gel should take special measures
● Pollution Level: 3
● Installation Type: Ⅲ
● Installation Position: should be installed in the absence of a significant shake and shock and vibration place
■ Install Location
■ Over Dimensions
● CJX2 – 09 ~ 32
● CJX2 – 40 ~ 95
Product Type | Amax | Bmax | Cmax | C1max | C2max | A | B | d |
CJX2-09~12 | 47 | 76 | 82 | 115 | 115 | 35 | 50/60 | 4.5 |
CJX2-18 | 47 | 76 | 87 | 120 | 120 | |||
CJX2-25 | 57 | 86 | 97 | 130 | 130 | 40 | 50/60 | 4.5 |
CJX2-32 | 57 | 86 | 102 | 135 | 135 | |||
CJX2-40~65 | 77 | 129 | 116 | 149 | 149 | 40 | 100/110 | 6.5 |
CJX2-80~95 | 87 | 129 | 127 | 160 | 160 | |||
